Flos C1 Double Spot Wall Large Ø56

Product Information:

Driver and wall mount are NOT included. They must be ordered separately for correct installation of the appliance.

C1 Double Spot Wall Large is an indoor LED spotlight, suitable for wall installation. The lower body of the product can be extracted from the installation surface and oriented 60° on the vertical axis and 180° on the horizontal axis. The simplicity of the cylinder hides an intelligent mechanism that allows to obtain an incredible flexibility of the lighting body. The optical unit set back inside the body hides the light source from view, controlling the direct luminance for a total comfort effect. The upper body of the spotlight projects the light upwards. C1 is suitable for all types of environments both contract (hotels, restaurants, shops, offices) and domestic. The double version includes as an accessory a diffusing screen that can be integrated inside the optical unit to create a soft light effect.

All luminaires must be powered with a remote driver NOT included, available with various control alternatives: 0 / 1-10V, DALI, Push Dimming and Casambi. Control system in broadcast mode. Double emission, direct and indirect, can be controlled independently.

• Light source: DC LED 950mA - 22W - 2100Lm / 1200mA - 28W - 2600Lm (integrated)
• Light temperature/Luminous flux: 2700K (1940/2450lm) / 3000K (2100/2600lm)
• Optic type: Medium - 23°
• Rotation: 180°
• Tilt: 60°
• Type of lighting: Direct (up and down) and Diffuse
• DIMMABLE (Driver excluded)
• Power source: Excluded
• Integrated accessory: Diffusing lens UP

Dimensions

• Diameter: Ø56 mm
• Lower part height: 157 mm
• Upper part height: 192 mm
• Wall connection: 35 mm

NOTES:

- For SURFACE INSTALLATION it is necessary to order the aluminum support. If you want to install it recessed, instead you need the NO-TRIM FRAME, compatible only with plasterboard surfaces. Both accessories can be ordered separately (see Installation Accessories).

-C1 Mono Spot Ceiling Large is available in the versions with Spot optic (15°), Flood optic (34°) or Wide Flood optic (45°) ON REQUEST.
