On sale!

Linea Light High Protection embossed lamp 13W

Linea Light High Protection tube 36 led for outdoor

Linea Light High Protection 36 topled lamp

Linea Light High Protection tube 36 led for outdoor

Name: Linea Light High Protection tube 36 led for outdoor
Brand: Linea Light
SKU: High Protection 36topLED

Brand Linea Light

$384.54

The product can be ordered

High Protection, 38mm linear colored tube 666mm long with 36 top LEDs, usable on the wall or ceiling for indoors or outdoors IP66, lamp made of polycarbonate, available in two different optics with green, red or blue LEDs.

Product Information:

High Protection is an elegant, linear LED lamp designed for both indoor and outdoor wall or ceiling installations. The anodized aluminum frame and UV-resistant polycarbonate diffuser with IP66 rating ensure durability and weather resistance. Composed of 36 state-of-the-art top LEDs, installed on a high-density PCB, with Extra Wide Flood light distribution. The lamp features a watertight closure by rotating anodized aluminum side caps. A special TCS valve acts as a protective air intake, preventing condensation inside the tube and ensuring stability and durability over time. The quick-connection system and integrated driver allow for the creation of continuous lines directly connected to the power grid. The orthogonal exit of the cable, minimizes the space between the tubes, creating the visual effect of a continuous and uniform light, with no visible gaps between sections. High Protection combines elegance and functionality, with a design that fits perfectly in modern spaces. Its simple line and colored light in red, green or blue is ideal for creating magical, enveloping atmospheres.

Material: Polycarbonate
Source: 36 topLED
Degree of protection: IP66
Insulation class: II
Optics: 105°(opal) - 107°x129°(embossed)
CRI: 80
Diode colors: red, green or blue
Height: 51mm
Length: 666mm
Diameter: 38mm

Red Diode

Power: 9.2 W DC - 10.2 W AC
Luminous Flux: 416Lm

Green Diode

Power: 13 W DC - 14.5 W AC
Luminous Flux: 995Lm

Blue Diode

Power: 13 W DC - 14.5 W AC
Luminous Flux: 198Lm

Please see the attached PDF for more information.

Notes: Connection cables NOT INCLUDED, a quick connect cable must be purchased for tube connection (see accessories). ONLY ON REQUEST it is possible to order the dimmable version with DALI protocol.

picture_as_pdf Datasheet

Available versions

Color:

Green -

Blue -

Red -

Finish:

Opal -

Embossed -

100% original product by

Details:

Data sheet

Reference: 95257R30
Length in mm: 666
Diameter in mm: 38
Degree of protection: IP66
Material: Polycarbonate
Light source: LED
Adjustable power: Not dimmable
Insulation class: Insulation class II
Mounting: Ceiling / Wall
Color rendering index: CRI80

Product accessories

On sale!

Cable extension for quick connect for High Protection tubes

Reference: 99217

Linea Light

Cable extension quick connect for High...

Available in different variants

Extension cable with ip66 male/female quick connectors for direct connection between Maytoni High Protection hoses. Available in two sizes.

$37.55

Shipped in 7-21 working days
